LED LIGHTING BOX

AITEC SYSTEM

LED LIGHTING for MACHINE VISION SYSTEM

APPEARANCE

FEATURES and APPLICATIONS

  1. ●Reaches 5,000,000 Lx
  2. ●A variety choices of emitted clolor (White, Red, Green, Blue)
  3. ●Lower power consumption(Under 150W)
  4. ●LED Makes it longer life and lesser maintenance costs
  5. ●Achieves steady and strong light
  6. ●We create unique heat radiation technology
  7. ●High linearity brightness control promises reliable light
  8. ●Ultra violet and infrared Rays-free light
  9. ●Extermal brightness control promises reliable light
  10. ●AC100-240V Input guarantees the univaersal use
  11. ●External control by RS232C,USB,LAN available(optional)
  12. ●A variety choices of the adaptors for any types of light guide
  13. ★Real alternative to halogen or metal halide lamps
  14. ★LED allows you to light objects with less heat (Machine vision use for metal,resin, film industries)
  15. ★For ispection in small place but hight illuminance required

SPECIFICATIONS

Model LLBB-NCW-SAW/R/G/B
Input Voltage AC100-240V±10% (50/60Hz)
Brightness 5,000,000Lx (Color: White) *1
Power Consumption Under 150W
Brightness Control ①Internal: By Brightness Volume
②External: DSUB, 8bits
③External powerON/OFF: DSUB
④LED disconnectin,overheat alarm
Lighting Method Constant Lighting
Cooling Method Forced air cooling
Available Light Guide Size Ø3 ~ 14mm
Optional ① Light guide attachment adaptor
② RS232C function
③ USB function
④ LAN function
Use Condition Temperature: 0 ~ 40°C
Humidity: 0 ~ 80%RH
(No Condensation)
Interior use only
LED Life time 30,000 hours *2
Standard RoHS, CE in process

*1 With Ø 10 fiber, 10mm from the end of the fiber(Rference values)

*2 Until the brightness decreases to 70%. It is a caliculated values.
